How To Test The Fuel Pump (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350)

The Ford F-series pickups with a returnless fuel system —the ones equipped with a fuel pump driver module (FPDM)— don't come with a fuel pressure test port on the fuel injector rail.

Although there's no Schrader valve (fuel pressure test port), you can still check fuel pressure using a test gauge.

In this tutorial, I'll show you how to do that step by step, so you can find out if the fuel pump is producing the correct pressure according to Ford's specs.

If you're troubleshooting an engine no-start, I'll also walk you through how to use starting fluid to check whether it's a fuel delivery issue.

APPLIES TO: This tutorial applies to the following FPDM equipped vehicles:

• 4.6L V8 Ford F150: 2004, 2005, 2006, 2007, 2008.
• 5.4L V8 Ford F150: 2004, 2005, 2006, 2007, 2008.
• 5.4L V8 Ford F250: 2005, 2006, 2007, 2008, 2009, 2010.
• 5.4L V8 Ford F350: 2005, 2006, 2007, 2008, 2009, 2010.

MORE FUEL PUMP DIAGNOSTIC RESOURCES: You can find fuel pump circuit wiring diagrams, related fuel pump tests, and the inertia switch tests in this section:

• More Fuel Pump Troubleshooting Help.

Symptoms Of A Bad Fuel Pump

The fuel pump in your F-Series pickup is going to fail in one of two ways:

• Total failure: In this scenario, the fuel pump simply stops working and doesn't deliver fuel anymore to the fuel injectors. The end result is an engine that won't start.
• Fuel pump slowly dying: The fuel pump still works, it does send some fuel up to the fuel injectors but not enough to keep the engine running optimally.

Now keep in mind, that we're talking about failures that have to do with the fuel pump itself, because in a returnless fuel system, quite a few things can go wrong and make you think that the fuel pump is toast.

OK, now if the fuel pump hasn't completely failed and it still sending some fuel up to the fuel injectors to where the engine starts, you're going to see one or more of the following symptoms:

1. Rough idle: Since the fuel pump isn't delivering enough fuel, the engine's gonna run lean, and this can end up causing a rough idle condition.
2. Hard start: You've got to crank the engine a while before it starts.
3. Lack of power: You'll feel this lack of power when you stick it in Drive and step on the gas, or when accelerating at cruising speed.
4. Backfires: Popping sounds coming from the intake manifold when the engine is under load.

Both of these conditions can be tested with a fuel pressure gauge. Alright, with this info under our belts, let's get testing.

Where To Buy A Fuel Pressure Test Gauge

To test the fuel pressure manually, you're going to need a fuel pressure test gauge kit that includes a Ford spring lock coupling adapter.

This Ford spring lock coupling adapter is placed in between the fuel injector rail and the fuel supply line. The fuel pressure test gauge is then connected to the adapter to read the fuel pump's pressure.

Besides the spring lock coupling adapter, you'll also going to need a quick release tool to release and disconnect the fuel line from the fuel injector rail.

If you don't have this a fuel pressure test kit with this spring lock coupling adapter or the quick release tool, you can buy one here:

Disclosure: As an Amazon Associate, I earn from qualifying purchases. Buying through these links helps support this site at no extra cost to you. Thanks for your support —it really means a lot!

TEST 1: Checking Fuel Pressure With A Fuel Pressure Gauge

Now, according to Ford's repair manual, the official way to check fuel pressure —on your pickup's fuel pump driver module (FPDM) equipped fuel system— is with a bi-directional scan tool that has live data capability.

With it, you can monitor the fuel rail pressure (FRP) sensor reading —Key On Engine Off (KOEO) or Key On Engine Running (KOER). If your scan tool is bi-directional, you can even command the fuel pump on with the engine off and watch the pressure that the FRP sensor reports.

But what if you don't have one? No problem. If you don't have a bi-directional scan tool (or even a basic scanner with live data) you can still test fuel pressure manually. And honestly, sometimes you have to, even if you have a scanner, just to be sure the FRP sensor hasn't failed and isn't feeding you bad info.

The step-by-step test instructions below have you covered —whether you're going in with a scan tool or doing it the old-school way with a gauge.

One quick tip before you start: check the fuel pump inertia switch and make sure it hasn't tripped. If it has, power won't reach the the fuel pump driver module (FPDM), and your pressure reading will be zero no matter what.

• Fuel Pump Inertia Switch Check.

NOTE: If you don't have a fuel pressure gauge, take a look at the section: Where To Buy A Fuel Pressure Test Gauge.

FUEL PRESSURE SPECIFICATION: You can find the specific fuel pressure specification for your particular F-Series pickup here: Fuel Pressure Specifications (1997-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).

OK, let's get started with this test:

1. 1

   Release the fuel pressure in the fuel line.

   See this section for the procedure: Fuel Pressure Release Procedure.

2. 2

   Disconnect the fuel supply line at the fuel injector rail.

3. 3

   Install the fuel pressure test adapter to the fuel injector rail's fuel supply inlet.

   This is the same port where you just disconnected the fuel line.

   NOTE: Be sure to follow your test kit's instructions to avoid any issues during setup.

4. 4

   Reconnect the fuel supply line to the adapter.

5. 5

   Connect your fuel pressure gauge to the adapter.

6. 6

   Have your helper cycle the key ON and OFF several times —but don't crank the engine.

   This will prime the system. Watch closely for leaks.

   If no leaks, you're good to go.

   If you see fuel leaking, stop and fix the leak before continuing.

KOEO Test (No Scan Tool): Engine doesn't start

1. 7

   Have your helper crank the engine, then release the key.

   NOTE: After cranking, the key should stay in the RUN position. If your helper turns it all the way to OFF, the test won't work —you'll need to do it again.

2. 8

   The fuel pressure gauge should show the fuel pressure within spec.

KOER Test (No Scan Tool): Engine starts and stays running

1. 7

   Have your helper start the engine and let it idle.

2. 8

   The fuel pressure gauge should show the fuel pressure within spec.

KOEO Test (No Scan Tool): Engine starts, but you need KOEO results

1. 7

   Disconnect both ignition coil packs or all 8 COP ignition coils from their electrical connectors.

2. 8

   Have your helper crank the engine, then release the key.

   NOTE: After cranking, the key should stay in the RUN position. If your helper turns it all the way to OFF, the test won't work —you'll need to do it again.

3. 9

   The fuel pressure gauge should show the fuel pressure within spec.

KOEO Test (With Scan Tool):

1. 7

   Connect your bidirectional scan tool to the OBD II diagnostic connector.

2. 8

   Turn the key to its RUN position but don't start the engine.

   NOTE: The fuel pump activation (with the bidirectional scan tool) is done with the engine OFF.

3. 9

   Enter component tests and activate the fuel pump.

   NOTE: Consult your scan tool's user manual for exact steps on how to access the fuel pump activation feature —the process can vary depending on the brand and model.

4. 10

   The fuel pressure gauge should show the fuel pressure within spec.

Let's break down what your fuel pressure test results are telling you:

CASE 1: The gauge shows 0 PSI. That's a clear sign the engine isn't getting fuel and that's why it's not starting.

We can't blame the fuel pump just yet. There's one more thing to rule out: we need to make sure the fuel pump driver module (FPDM) isn't toast.

Testing the FPDM isn't difficult, and I've written a full tutorial that walks you through it. You can find it here:

• Fuel Pump Driver Module Tests (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).

CASE 2: The gauge shows pressure, but it's below spec. That usually means the pump is weak —it's still running, but it's not delivering enough pressure.

If there are no fuel rail pressure (FRP) sensor or fuel pump driver module (FPDM) diagnostic trouble codes, the fuel pump is failing and needs to be replaced.

CASE 3: The pressure is within spec. That's good news. We can conclude the fuel pump is doing its job and supplying the right pressure to the injectors.

So, if your F-Series still won't start, you can rule out the fuel pump and keep digging. The problem lies elsewhere.

TEST 2: Using Starting Fluid To Confirm Lack Of Fuel

I've been using starting fluid to troubleshoot engine no-start problems since my early days working on cars —back when carburetors still ruled the road!

Even though times (and fuel systems) have changed, this little test still works like a charm —yep, even on today's fuel-injected engines.

Now, I do want to let you know that this method isn't as precise as hooking up a fuel pressure gauge. But what it will do is tell you whether your no-start problem is likely being caused by a lack of fuel (and yes, that includes a faulty fuel pump).

But here's the catch: this test only works if you've already confirmed that all eight cylinders are getting spark. Without that, your results won't mean much. So if you haven't checked for spark yet, go do that first.

The way this test works, is if you spray starting fluid into the throttle body, and the engine starts —even just for a second— it means fuel is missing from the combustion formula (fuel + spark + air = boom).

IMPORTANT: For this test to give you useful results, you've got to verify spark on all cylinders first. No shortcuts here.

IMPORTANT: After spraying starting fluid into the throttle, always reconnect the air intake duct before cranking —even if you don't clamp it down. This helps prevent a backfire from possibly spitting flames onto the engine.

Here's how to run the starting fluid test step by step:

1. 1

   Loosen and pull the intake air duct off the throttle body. You don't need to remove it completely —you'll be reconnecting it in just a bit.

2. 2

   Manually open the throttle plate and spray a solid shot of starting fluid into the bore.

3. 3

   Reattach the air duct once you've sprayed the fluid.

   No need to tighten the hose clamp —just make sure it's sitting in place.

4. 4

   Crank the engine after you've reconnected the duct and are clear of the engine bay.

5. 5

   One of two things is going to happen:

   1.) The engine fires up briefly and then dies out.

   2.) The engine cranks, but never starts —not even for a moment.

Now let's go over what those results mean:

CASE 1: The engine started and ran for a couple of seconds. That's your confirmation the issue is fuel-related —the engine started because you gave it fuel manually.

Chances are high that the fuel pump isn't doing its job. But to be sure, I recommend backing this up with a pressure test. You'll find that here: TEST 1: Checking Fuel Pressure With A Fuel Pressure Gauge.

CASE 2: The engine didn't even try to start. That usually means your no-start issue isn't caused by lack of fuel.

Still, like I mentioned earlier, this method isn't bulletproof. So just to cover your bases, grab your fuel pressure gauge and run a proper pressure test. Here's how: TEST 1: Checking Fuel Pressure With A Fuel Pressure Gauge.

Fuel Pump Inertia Switch Check

Your F-Series pickup comes with a built-in safety feature designed to cut power to the fuel pump in the event of a collision (whether you hit something or something hits you).

This device is called the fuel pump inertia switch, and its job is simple: shut off power to the fuel pump driver module (which activates the fuel pump) during a crash —so that if any fuel lines were ruptured, fuel doesn't spray everywhere and start a fire.

But here's the thing, since this switch is mechanical, it doesn't take a major accident to trigger it. Hitting a deep pothole, bumping a curb just right, or even slamming the door too hard can trip it.

So before you break out the fuel pressure gauge, it's important to check whether the inertia switch has tripped. And luckily, it's easy to do.

You'll find the fuel pump inertia switch behind the passenger-side kick panel (that's the plastic trim right under the dash on the right side of the cab).

Once you locate it, just press down firmly on the red button at the top of the switch. If it was tripped, you'll feel and hear a click as it resets into place.

Fuel Pressure Release Procedure

Before disconnecting the fuel line to install the Ford spring lock adapter onto the fuel injector rail, you'll want to bleed off the pressure in the fuel line first. If the fuel line has any fuel pressure, this safety step helps you avoid having fuel getting sprayed all over the engine.

Here's the pressure release procedure:

1. Disconnect the fuel pump's connector:
   • This connector sits above the fuel tank, but is still visible, no need to drop the tank to access it.
2. Crank the engine: If it starts, let it run until it stalls out.
3. Crank it again a few more times: Do this until the engine no longer fires at all.
4. Wrap a shop towel around the fuel line and disconnect it from the injector rail:
   • The towel helps catch any remaining fuel in the line.
5. Reconnect the fuel pump's connector: Once the line is disconnected and things are dry, put the fuse back in place.
6. Clear any trouble codes: If any DTCs popped up while cranking with the pump disabled, go ahead and erase them after the test is complete.
