The 1997-2010 4.6L/5.4L V8 F150, F250, and F350 pickup fuel pressure specifications.
| F150 | |||
|---|---|---|---|
| Year | Engine | KOEO | KOER |
| 1997 | 4.6L/5.4L | 30-45 PSI | 27-42 PSI |
| 1998-2008 | 4.6L/5.4L | 34-45 PSI | 28-45 PSI |
| 2009-2010 | 4.6L/5.4L | 55-60 PSI | 55-60 PSI |
| F250 | |||
|---|---|---|---|
| Year | Engine | KOEO | KOER |
| 1998-1999 | 4.6L/5.4L | 34-45 PSI | 28-45 PSI |
| 2000-2010 | 5.4L | 34-45 PSI | 28-45 PSI |
| F350 | |||
|---|---|---|---|
| Year | Engine | KOEO | KOER |
| 1999-2010 | 5.4L | 34-45 PSI | 28-45 PSI |
KOEO = Key On Engine Off.
KOER = Key On Engine Running.
FUEL PUMP PRESSURE TESTS:
- How To Test The Fuel Pump (1997-2004 4.6L, 5.4L V8 Ford F150, F250, And F350).
- How To Test The Fuel Pump (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).
POWER TO FUEL PUMP TESTS:
FUEL PUMP DRIVE MODULE (FPDM) TESTS:
- FPDM Basic Operating Theory (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).
- Fuel Pump Driver Module Tests (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).
- Bypassing The FPDM Module (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).
- Safely Probing The FPDM Connector (2004-2010 4.6L, 5.4L V8 Ford F150, F250, And F350).
Where To Buy A Fuel Pressure Gauge
The following fuel pressure test kits have the Ford Schrader valve adapter you'll need to connect the fuel test gauge to the fuel injector rail:
